按您要求来做包装,如有需要,欢迎随时询价!
Bearing Number | Boundary dimensions(mm) | Basic load ratings(kN) | Limiting speeds(rpm) | Mass(Kg) | ||||||
d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) | ||
62 Series | 6200 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.032 |
6201 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.037 | |
6202 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.045 | |
6203 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.066 | |
6204 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.106 | |
6205 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.128 | |
6206 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.199 | |
6207 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.288 | |
6208 | 40 | 80 | 18 | 1.1 | 29.1 | 17.8 | 8,700 | 10,000 | 0.366 | |
6209 | 45 | 85 | 19 | 1.1 | 32.5 | 20.4 | 7,800 | 9,200 | 0.398 | |
6210 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 7,100 | 8,300 | 0.454 | |
6211 | 55 | 100 | 21 | 1.5 | 43.5 | 29.2 | 6,400 | 7,600 | 0.601 | |
6212 | 60 | 110 | 22 | 1.5 | 52.5 | 36 | 6,000 | 7,000 | 0.783 | |
6213 | 65 | 120 | 23 | 1.5 | 57.5 | 40 | 5,500 | 6,500 | 0.99 | |
6214 | 70 | 125 | 24 | 1.5 | 62 | 44 | 5,100 | 6,000 | 1.07 | |
6215 | 75 | 130 | 25 | 1.5 | 66 | 49.5 | 4,800 | 5,600 | 1.18 | |
6216 | 80 | 140 | 26 | 2 | 72.5 | 53 | 4,500 | 5,300 | 1.4 | |
6217 | 85 | 150 | 28 | 2 | 83.5 | 64 | 4,200 | 5,000 | 1.79 | |
6218 | 90 | 160 | 30 | 2 | 96 | 71.5 | 4,000 | 4,700 | 2.15 | |
6219 | 95 | 170 | 32 | 2.1 | 109 | 82 | 3,700 | 4,400 | 2.62 | |
6220 | 100 | 180 | 34 | 2.1 | 122 | 93 | 3,500 | 4,200 | 3.14 | |
6221 | 105 | 190 | 36 | 2.1 | 133 | 105 | 3,400 | 4,000 | 3.7 | |
6222 | 110 | 200 | 38 | 2.1 | 144 | 117 | 3,200 | 3,800 | 4.36 | |
6224 | 120 | 215 | 40 | 2.1 | 155 | 131 | 2,900 | 3,400 | 5.15 | |
6226 | 130 | 230 | 40 | 3 | 167 | 146 | 2,700 | 3,100 | 5.82 | |
6228 | 140 | 250 | 42 | 3 | 166 | 150 | 2,500 | 2,900 | 7.57 | |
6230 | 150 | 270 | 45 | 3 | 176 | 168 | 2,300 | 2,700 | 9.41 | |
6232 | 160 | 290 | 48 | 3 | 185 | 186 | 2,100 | 2,500 | 11.7 | |
6234 | 170 | 310 | 52 | 4 | 212 | 223 | 2,000 | 2,400 | 14.5 | |
6236 | 180 | 320 | 52 | 4 | 227 | 241 | 1,900 | 2,200 | 15.1 | |
6238 | 190 | 340 | 55 | 4 | 255 | 281 | 1,800 | 2,100 | 18.2 | |
6240 | 200 | 360 | 58 | 4 | 269 | 310 | 1,700 | 2,000 | 21.6 | |
6244 | 220 | 400 | 65 | 4 | 297 | 365 | 1,500 | 1,800 | 30.2 | |
62/22 | 22 | 50 | 14 | 1 | 1320 | 690 | 14,000 | 17,000 | 0.117 | |
62/28 | 28 | 58 | 16 | 1 | 1830 | 995 | 12,000 | 14,000 | 0.171 | |
62/32 | 32 | 65 | 17 | 1 | 2110 | 1190 | 11,000 | 12,000 | 0.226 | |
62...C3 Series | 6200C3 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.032 |
6201C3 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.037 | |
6202C3 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.045 | |
6203C3 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.066 | |
6204C3 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.106 | |
6205C3 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.128 | |
6206C3 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.199 | |
6207C3 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.288 | |
6208C3 | 40 | 80 | 18 | 1.1 | 29.1 | 17.8 | 8,700 | 10,000 | 0.366 | |
6209C3 | 45 | 85 | 19 | 1.1 | 32.5 | 20.4 | 7,800 | 9,200 | 0.398 | |
6210C3 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 7,100 | 8,300 | 0.454 | |
6211C3 | 55 | 100 | 21 | 1.5 | 43.5 | 29.2 | 6,400 | 7,600 | 0.601 | |
6212C3 | 60 | 110 | 22 | 1.5 | 52.5 | 36 | 6,000 | 7,000 | 0.783 | |
6213C3 | 65 | 120 | 23 | 1.5 | 57.5 | 40 | 5,500 | 6,500 | 0.99 | |
6214C3 | 70 | 125 | 24 | 1.5 | 62 | 44 | 5,100 | 6,000 | 1.07 | |
6215C3 | 75 | 130 | 25 | 1.5 | 66 | 49.5 | 4,800 | 5,600 | 1.18 | |
6216C3 | 80 | 140 | 26 | 2 | 72.5 | 53 | 4,500 | 5,300 | 1.4 | |
6217C3 | 85 | 150 | 28 | 2 | 83.5 | 64 | 4,200 | 5,000 | 1.79 | |
6218C3 | 90 | 160 | 30 | 2 | 96 | 71.5 | 4,000 | 4,700 | 2.15 | |
6219C3 | 95 | 170 | 32 | 2.1 | 109 | 82 | 3,700 | 4,400 | 2.62 | |
6220C3 | 100 | 180 | 34 | 2.1 | 122 | 93 | 3,500 | 4,200 | 3.14 | |
6221C3 | 105 | 190 | 36 | 2.1 | 133 | 105 | 3,400 | 4,000 | 3.7 | |
6222C3 | 110 | 200 | 38 | 2.1 | 144 | 117 | 3,200 | 3,800 | 4.36 | |
6224C3 | 120 | 215 | 40 | 2.1 | 155 | 131 | 2,900 | 3,400 | 5.15 | |
6226C3 | 130 | 230 | 40 | 3 | 167 | 146 | 2,700 | 3,100 | 5.82 | |
6228C3 | 140 | 250 | 42 | 3 | 166 | 150 | 2,500 | 2,900 | 7.57 | |
6230C3 | 150 | 270 | 45 | 3 | 176 | 168 | 2,300 | 2,700 | 9.41 | |
6232C3 | 160 | 290 | 48 | 3 | 185 | 186 | 2,100 | 2,500 | 11.7 | |
6234C3 | 170 | 310 | 52 | 4 | 212 | 223 | 2,000 | 2,400 | 14.5 | |
6236C3 | 180 | 320 | 52 | 4 | 227 | 241 | 1,900 | 2,200 | 15.1 | |
6238C3 | 190 | 340 | 55 | 4 | 255 | 281 | 1,800 | 2,100 | 18.2 | |
6240C3 | 200 | 360 | 58 | 4 | 269 | 310 | 1,700 | 2,000 | 21.6 | |
6244C3 | 220 | 400 | 65 | 4 | 297 | 365 | 1,500 | 1,800 | 30.2 | |
62... Series | 62/22-2RDC3P6QE6 | 22 | 50 | 14 | 1 | 1320 | 690 | 12,000 | 0.117 | |
62/22-2RS | 22 | 50 | 14 | 1 | 1320 | 690 | 12,000 | 0.117 | ||
62/22-2RSC3 | 22 | 50 | 14 | 1 | 1320 | 690 | 12,000 | 0.117 | ||
62/22-ZZ | 22 | 50 | 14 | 1 | 1320 | 690 | 12,000 | 0.117 | ||
62/22-ZZC3 | 22 | 50 | 14 | 1 | 1320 | 690 | 12,000 | 0.117 | ||
62/28-2RDC3P6QE6 | 28 | 58 | 16 | 1 | 1830 | 995 | 9,700 | 0.171 | ||
62/28-2RS | 28 | 58 | 16 | 1 | 1830 | 995 | 9,700 | 0.171 | ||
62/28-2RSC3 | 28 | 58 | 16 | 1 | 1830 | 995 | 9,700 | 0.171 | ||
62/28-ZZ | 28 | 58 | 16 | 1 | 1830 | 995 | 9,700 | 0.171 | ||
62/28-ZZC3 | 28 | 58 | 16 | 1 | 1830 | 995 | 9,700 | 0.171 | ||
62/32-2RDC3P6QE6 | 32 | 65 | 17 | 1 | 2110 | 1190 | 8,400 | 0.226 | ||
62/32-2RS | 32 | 65 | 17 | 1 | 2110 | 1190 | 8,400 | 0.226 | ||
62/32-2RSC3 | 32 | 65 | 17 | 1 | 2110 | 1190 | 8,400 | 0.226 | ||
62/32-ZZ | 32 | 65 | 17 | 1 | 2110 | 1190 | 8,400 | 0.226 | ||
62/32-ZZC3 | 32 | 65 | 17 | 1 | 2110 | 1190 | 8,400 | 0.226 | ||
6200-2RDC3P6QE6 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 21,000 | 0.032 | ||
6200-2RS | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 0.032 | ||
6200-2RSC3 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 0.032 | ||
6200-N | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.032 | |
6200-NR | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.034 | |
6200-RS | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 30,000 | 0.032 | ||
6200-RSC3 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 30,000 | 0.032 | ||
6200-Z | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 30,000 | 0.032 | ||
6200-ZC3 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 30,000 | 0.032 | ||
6200-ZNR | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.034 | |
6200-ZZ | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 0.032 | ||
6200-ZZC3 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 0.032 | ||
6200-ZZC3P6QE6 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 0.032 | ||
6201-2RDC3P6QE6 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 20,000 | 0.037 | ||
6201-2RS | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 0.037 | ||
6201-2RSC3 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 0.037 | ||
6201-N | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.037 | |
6201-NR | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.039 | |
6201-RS | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 26,000 | 0.037 | ||
6201-RSC3 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 26,000 | 0.037 | ||
6201-Z | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 26,000 | 0.037 | ||
6201-ZC3 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 26,000 | 0.037 | ||
6201-ZNR | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.039 | |
6201-ZZ | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 0.037 | ||
6201-ZZC3 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 0.037 | ||
6201-ZZC3P6QE6 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 0.037 | ||
6202-2RDC3P6QE6 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 18,000 | 0.045 | ||
6202-2RS | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 0.045 | ||
6202-2RSC3 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 0.045 | ||
6202-N | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.045 | |
6202-NR | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.047 | |
6202-RS | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 23,000 | 0.045 | ||
6202-RSC3 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 23,000 | 0.045 | ||
6202-Z | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 23,000 | 0.045 | ||
6202-ZC3 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 23,000 | 0.045 | ||
6202-ZNR | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.047 | |
6202-ZZ | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 0.045 | ||
6202-ZZC3 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 0.045 | ||
6202-ZZC3P6QE6 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 0.045 | ||
6203-2RDC3P6QE6 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 15,000 | 0.066 | ||
6203-2RS | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 0.066 | ||
6203-2RSC3 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 0.066 | ||
6203-N | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.066 | |
6203-NR | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.068 | |
6203-RS | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 21,000 | 0.066 | ||
6203-RSC3 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 21,000 | 0.066 | ||
6203-Z | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 21,000 | 0.066 | ||
6203-ZC3 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 21,000 | 0.066 | ||
6203-ZNR | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.068 | |
6203-ZZ | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 0.066 | ||
6203-ZZC3 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 0.066 | ||
6203-ZZC3P6QE6 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 0.066 | ||
6204-2RDC3P6QE6 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 12,000 | 0.106 | ||
6204-2RS | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 0.106 | ||
6204-2RSC3 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 0.106 | ||
6204-N | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.106 | |
6204-NR | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.11 | |
6204-RS | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 18,000 | 0.106 | ||
6204-RSC3 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 18,000 | 0.106 | ||
6204-Z | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 18,000 | 0.106 | ||
6204-ZC3 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 18,000 | 0.106 | ||
6204-ZNR | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.11 | |
6204-ZZ | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 0.106 | ||
6204-ZZC3 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 0.106 | ||
6204-ZZC3P6QE6 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 0.106 | ||
6205-2RDC3P6QE6 | 25 | 52 | 15 | 1 | 14 | 7.85 | 11,000 | 0.128 | ||
6205-2RS | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 0.128 | ||
6205-2RSC3 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 0.128 | ||
6205-N | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.128 | |
6205-NR | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.132 | |
6205-RS | 25 | 52 | 15 | 1 | 14 | 7.85 | 15,000 | 0.128 | ||
6205-RSC3 | 25 | 52 | 15 | 1 | 14 | 7.85 | 15,000 | 0.128 | ||
6205-Z | 25 | 52 | 15 | 1 | 14 | 7.85 | 15,000 | 0.128 | ||
6205-ZC3 | 25 | 52 | 15 | 1 | 14 | 7.85 | 15,000 | 0.128 | ||
6205-ZNR | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.132 | |
6205-ZZ | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 0.128 | ||
6205-ZZC3 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 0.128 | ||
6205-ZZC3P6QE6 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 0.128 | ||
6206-2RDC3P6QE6 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 8,800 | 0.199 | ||
6206-2RS | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 0.199 | ||
6206-2RSC3 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 0.199 | ||
6206-N | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.199 | |
6206-NR | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.206 | |
6206-RS | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 13,000 | 0.199 | ||
6206-RSC3 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 13,000 | 0.199 | ||
6206-Z | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 13,000 | 0.199 | ||
6206-ZC3 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 13,000 | 0.199 | ||
6206-ZNR | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.206 | |
6206-ZZ | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 0.199 | ||
6206-ZZC3 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 0.199 | ||
6206-ZZC3P6QE6 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 0.199 | ||
6207-2RDC3P6QE6 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 7,600 | 0.288 | ||
6207-2RS | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 0.288 | ||
6207-2RSC3 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 0.288 | ||
6207-N | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.288 | |
6207-NR | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.298 | |
6207-RS | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 11,000 | 0.288 | ||
6207-RSC3 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 11,000 | 0.288 | ||
6207-Z | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 11,000 | 0.288 | ||
6207-ZC3 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 11,000 | 0.288 | ||
6207-ZNR | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.298 |
